Led Working Light
Model:LWC-2
Image Sensor 1/3 AR0130
TV System NTSC/PAL
Effective Pixels 1280（H）ⅹ960（V）
Sensing Area 3.75μm
Sync. System Internal
Resolution 130W
TV System NTSC/PAL
Effective Pixels 1280（H）ⅹ960（V）
Sensing Area 3.75μm
Sync. System Internal
Resolution 130W
Features
Minimum Illumination 0.1 Lux (day), 0 Lux (with IR)
IR LED Qty white light*8PCS
Light type 60° floodlight
Night vision distance 30-50m
Microphone NO
Video Output 1.0 Vp-p/75 Ohm
Scanning System interlace
AGC AUTO
Signal to noise ratio Better than 48dB
IR LED Qty white light*8PCS
Light type 60° floodlight
Night vision distance 30-50m
Microphone NO
Video Output 1.0 Vp-p/75 Ohm
Scanning System interlace
AGC AUTO
Signal to noise ratio Better than 48dB
Parameter
Image Sensor | 1/3 AR0130 |
TV System | NTSC/PAL |
Effective Pixels | 1280（H）ⅹ960（V） |
Sensing Area | 3.75μm |
Sync. System | Internal |
Resolution | 130W |
Minimum Illumination | 0.1 Lux (day), 0 Lux (with IR) |
IR LED Qty | white light*8PCS |
Light type | 60° floodlight |
Night vision distance | 30-50m |
Microphone | NO |
Video Output | 1.0 Vp-p/75 Ohm |
Scanning System | interlace |
AGC | AUTO |
Signal to noise ratio | Better than 48dB |
White balance | AUTO |
Gamma Consumption | 0.45 |
Electronic Shutter | AUTO |
Backlight Compensation | AUTO |
Lens | 1.7mm |
Lens Angle | 140° |
LED lamp plate voltage | DC12-24V |
LED lamp board power | 24W |
Luminous flux / lumen | 1154/lm |
Color temperature | 6000K |
Lens material | PC |
Power Supply | DC12V |
Current Drain | 70±5mA (day)/2.33±5A(night vision) |
Operating Temperature | -20℃-70℃,RH 95% MAX |
Storage Temperature | -30℃-80℃,RH 95% MAX |
Application
Accessories
