License Plate Camera
Model:CA-303
600 TVL
wide viewing angle(150°)
Waterproof grade IP69K
With night vision function
wide viewing angle(150°)
Waterproof grade IP69K
With night vision function
Features
Parameter
Image Sensor | 1/3 CMOS |
TV System | NTSC/PAL |
Effective Pixels | 728(H)*488(V) |
Sensing Area | 4.623mm*3.611mm |
Sync. System | Internal |
Resolution | 600 TVL |
Minimum Illumination | 0.1 Lux (day), 0 Lux (with IR) |
Microphone | Optional |
IR LED Qty | 5PCS |
Video Output | 1.0 Vp-p/75 Ohm |
Scanning System | interlace |
AGC | AUTO |
Signal to noise ratio | Better than 48dB |
White balance | AUTO |
Gamma Consumption | 0.45 |
Electronic Shutter | AUTO |
Backlight Compensation | AUTO |
Power Supply | DC12V |
Lens | 1.7mm |
Lens Angle | 150° |
Current Drain | 65±5mA |
Operating Temperature | -20℃-70℃,RH 95% MAX |
Storage Temperature | -30℃-80℃,RH 95% MA |
