Heavy duty HD Camera

TV System

NTSC/PAL

Effective Pixels

1920(H)×1080(V)

Sensing Area

2.8μm（H）ⅹ 2.8μm（V）

Sync. System

Internal

Resolution

200W

Minimum Illumination

0.1 Lux (day), 0 Lux (with IR)

Microphone

Optional

IR LED Qty

12PCS

Video Output

1.0 Vp-p/75 Ohm

Scanning System

interlace

AGC

AUTO

Signal to noise ratio

Better than 48dB

White balance

AUTO

Gamma Consumption

0.45

Electronic Shutter

AUTO

Backlight Compensation

AUTO

Power Supply

DC12V

Lens

2.8mm

Lens Angle

122°

Current Drain

70±5mA

Operating Temperature

-20℃-70℃,RH 95% MAX

Storage Temperature

-30℃-80℃,RH 95% MAX
